aper size

Perfect binder tray

• Body

Standard: A4 , B5 , A5 /, 8.5  11 , 5.5  8.5 /, 16K

Custom: Widthwise 139 mm to 307 mm, Lengthwise 210 mm to 221 mm / Widthwise 5.47" to 12.09", Lengthwise 8.27" to 8.7"

• Cover paper

Standard: SRA3 , A3  , B4 , SRA4 /, A4 /, B5 /, A5 /, B6 , A6 , 13  19 , 12  18 , 11  17 , 9  11 , 8.5  14 , 8.5  11 /, 7.25  10.5 /, 5.5  8.5 /, Foolscap*, 8K , 16K /

Custom: Widthwise 95 mm to 331 mm, Lengthwise 139 mm to 488 mm / Widthwise 3.74" to 13.03", Lengthwise 5.47" to 19.21"

Tab paper: A4T , 8.5  11T

*: Foolscap refers to 8.5  13 , 8.25  13 , 8.12  13.25 , and 8  13 .

Paper weight

Perfect binder tray

Body: 64 g/m² to 105 g/m² / 17 lb Bond to 28 lb Bond, Cover paper: 81 g/m² to 216 g/m² / 22 lb Bond to 57 lb Bond

Secondary (sub) tray

40 g/m² to 350 g/m² / 11 lb Bond to 93 lb Bond

Paper type

Perfect binder tray

Body: Plain, Fine, Color, Coated-ML, Coated-MO

Cover: Fine, Coated

Secondary (sub) tray

All types of paper to be used in the machine

Stack capacity

Cover tray

1,000 sheets (82 g/m² / 23 lb Bond), 500 sheets (216 g/m² / 57 lb Bond)

Perfect binder tray

For a set of the maximum thickness of 30 mm / 1.18" booklets (approx. 300 sheets): 11 sets  2 columns (approx. 6,600 sheets). The capacity is limited to prevent the piled sets from collapsing. It varies depending on the number of body sheets as follows. 10 to 30-sheet-bound set: 50 sets; 31 to 150-sheet-bound set: 35 sets or until detected as full load; 151 to 300-sheet-bound set: Until detected as full load

Secondary (sub) tray

200 sheets (80 g/m² / 21 lb Bond) (with the full-load detection function activated)

Cover Trim

Trim: ON or OFF can be selected.

Warm-up time

Approx. 20 minutes

Dimensions

1,360 mm (W)  775 mm (D)  1,223 mm (H) / 53.54" (W) x 30.51" (D) x 48.15" (H)

Weight

Approx. 270 kg / 595.24 lb

Power source

Metric area: AC 220 V to 240 V, 50/60 Hz

Inch area: AC 120 V, 60 Hz

Maximum power consumption

1,000 W or less
